Key Features and Specifications of the DNS 8 Live
Key Features
- Eight channels of dialogue noise suppression
- A unique DNS algorithm with rapid 2-knob setup per channel
- Detailed DNS mode ideal for permanent installations
- 1U rackmount with 90V-250V universal PSU and 12VDC input
Audio Specifications
- I/O type: Digital PCM
- Audio formats: AES3 on XLR sockets plus DB25 (AES59 pin-out)
- Sample rates: 44.1, 48, 88.2, 96 kHz
- I/O resolution: 24 bits
- Process resolution: 40 bits, floating-point
- Processor power: 3.9 GFLOPS
- Latency: <10 samples (0.2ms at 44.1kHz)
- Fail-safe audio bypass
Physical Specifications
- Mains power: 90-260VAC; 50-60Hz auto-selecting
- DC power: 12VDC on standard 4-pin connector
- Size: 1U rackmount, 20cm depth
- Weight: 3Kg
DNS Control System
- Web-based remote control for laptops, tablets, and other devices
- Works on almost any browser
- Independent of DAWs
- Not limited to specific operating systems
- Ethernet interface
The Company reserves the right to change specifications without notice. E&OE.
